Hose ID | Hose OD | W.P | B.P | Min Bend Radius | Weight | |||
inch | mm | mm | MPa | Psi | MPa | Psi | mm | kg/m |
1/8 | 3.3 | 8.5 | 17.2 | 2500 | 68.9 | 10000 | 13 | 0.037 |
3/16 | 4.8 | 10.8 | 20.7 | 3002 | 82.7 | 12008 | 20 | 0.068 |
1/4 | 6.4 | 13.0 | 20.7 | 3002 | 82.7 | 12008 | 33 | 0.085 |
5/16 | 7.9 | 15.1 | 17.2 | 2500 | 68.9 | 10000 | 46 | 0.103 |
3/8 | 9.5 | 17.0 | 15.5 | 2450 | 62.1 | 10280 | 51 | 0.141 |
1/2 | 12.7 | 20.7 | 13.8 | 2002 | 55.2 | 9800 | 76 | 0.210 |
5/8 | 15.9 | 23 | 11.5 | 1668 | 45 | 6672 | 102 | 0.245 |
3/4 | 19.0 | 27.1 | 8.6 | 1250 | 34.5 | 5000 | 127 | 0.287 |
1 | 25.4 | 34 | 6.9 | 1000 | 27.6 | 4000 | 203 | 0.542 |
SAE 100R7
STRUCTURE AND CAPABILITY:
This kinds of hose is made of inner tube ( Nylon ), reinforcement (High Pressure Synthetic Fiber ) , and cover ( High Flexibility Nylon or Thermoplastic ) . lt is lightweight,flexible and the inner tube is very smooth. With few loss of pressure, the hose resistance of themedium flowing is small, and it also owns a fine performance of anti-chemical and impulse.
APPLICATION:
Automobile,Engineering Machinery, Lathe, Agriculture Machine,Mining, Spurtingthe Oil Paint, Avigation & Spaceflight, Cooling and other Hydraulic Control System.
